BT2.0 Connector – η πιο σημαντική επανάσταση στο 1S Whoop Drone.
Δεν είστε σίγουροι αν αξίζει να μεταβείτε στην υποδοχή BT2.0; Δείτε περισσότερα από το Joshua’video- Απόδειξη ότι η υποδοχή BT2.0 είναι καλύτερη από το PH 2.0
Από τον Φεβρουάριο του 2019, έχουμε μερικά σχόλια στο Facebook σχετικά με το πόσο ανυπόμονοι χρειάζονται την υψηλή ποιότητα της σύνδεσης στερεών ακίδων στο 1S whoop drone. Έτσι ξεκινήσαμε τη μακροχρόνια έρευνά μας σχετικά με το σχεδιασμό των συμπαγών ακίδων και τη σταθερή τεχνική κατασκευής για να καλύψουμε τη ζήτηση των πιλότων. Το Betafpv συνεχίζει πάντα να προχωρά με πάθος για πρωτοποριακές εμπειρίες.
Τώρα κυκλοφόρησε επιτέλους η μπαταρία 1S με την αποκλειστική σχεδίαση του συνδετήρα BT2.0 της Betafpv, η οποία έχει σπάσει το λαιμό των άχρηστων πτερυγίων PH2.0. Εν τω μεταξύ, παρέχουμε 200 σετ μπαταρίας BT2.0 300mah 1S (2 τμχ) και έναν ορισμένο αριθμό υποδοχών BT2.0 ως δωρεάν δώρο για όλους. Κάντε κλικ εδώ για να πάρετε την μπαταρία/βύσμα BT2.0.
Bullet Point
- BT2.0 connector decreased internal resistance of connector effectively by upgrading the crimped pins to 1.0mm banana connector and increasing the cross-sectional area of 1.0mm banana connector.
- BT2.0 300mAh 1S 30C Battery supports 9A continuous current and 15A burst, while the PH2.0 connector supports 4.5A continuous current. With this BT2.0 300mAh 1S battery, all 1S brushless drones will gain powerful and perfect performance.
- By solving the problem of voltage sag, the discharge of the 300mAh 1S BT2.0 lipo becomes more efficient. Pilots can enjoy more flight time without disturbance of low voltage warning.
- Compared with the PH2.0 crimped pins, the BT2.0 connector is more durable which can discharge more currents in the same capacity and provide far more power. You can get a 2mins flight time in full throttle on Meteor65.
- The package comes with a BT2.0-PH2.0 adapter cable package, which is convenient to charge the BT2.0 battery with a stock PH2.0 charger. Meanwhile, we also release BT2.0 all-in-one battery Tester & charger for your need.
SPECIFICATION
- Item: 1S battery
- Capacity: 300mAh
- Rate: 30C/60C
- Voltage: 4.35V
- Dimension: 67.3*11.8*6.1mm
- Connector: Betafpv BT2.0 connector
- Weight: 8.28g(1pcs)
BT2.0 Connector
There is a graph of comparison between BT2.0 connector and PH2.0 connector (solid pins version) in BETAFPV 1S 300mAh battery. The discharge current is 9A in this testing. You could see that it has double time ( about 2minutes) and a 0.2v improvement in voltage sag with BT2.0 connector.
Πολύ περισσότερες επιλογές αξεσουάρ της σειράς BT2.0.
We know some pilots might have a question about how to deal with the old PH2.0 1S battery. So we provide some accessories like BT2.0 Power whoop connectors for those people who wanna convert the PH2.0 connector to BT2.0 connector.
- BT2.0 Connectors (10pcs)
- BT2.0 1S Whoop Cable Pigtail
- BT2.0-PH2.0 Adapter Cable
Highly recommend the below products with BT2.0 connectors or cables. BETAFPV will collaborate closely with more brand manufacturers in the future, in order to bring better service and experience to customers.
- BT2.0 450mAh 1S Battery
- BT2.0 300mAh 1S Battery
- BT2.0 Battery Charger and Voltage Tester
- BT2.0 Series Quadcopters
- 6 Ports 1S Battery Charger & Adapter
- Other Brand Chargers & Batteries with BT2.0 port
Difference between BT2.0 battery and PH2.0 battery
As we can see, the BT2.0 300mah 1S battery is adopted with the 1.0mm banana connector while the PH2.0 battery is the crimped pins. Also, it is a bit longer than the original PH2.0 battery, which is marked BT2.0 on the label.
Here is a Betafpv Lab video to show you the best way of replacing BT2.0 connectors.
PACKAGE
- 8 * BT2.0 300mAh 1S 30C Battery
